TETRON Can Satisfy Your Different Mission Needs!

TETRON allows you to use the payload you need at high altitudes and for extended periods.

Autonomous Mission Capability:

TETRON is supplied with a flight control system that eliminates the need for piloting. The system is capable of autonomous take-off, flight and landing without the need for global positioning systems. It also ensures that the drone remains within a certain area and operates safely even under windy conditions.

Compatible with different drones:

Tetron Compatible With More Than 10 Drones.

Uninterrupted Mission Capability:

TETRON’s electronic architecture that covers the entire system provides you with an uninterrupted mission capability.

Portable Watchtower:

TETRON can operate as a 100 m observation tower in any location.

Covert Operation:

TETRON maintains communication with the ground via a cable, and so is immune to detection and interception by electronic warfare systems.

Resistance to Anti-Drone Systems:

TETRON makes all necessary communications via the cable connecting it to the ground, preventing jamming by anti-drone systems.

There is a TETRON for Every User:

TETRON addresses the varying needs of the armed forces, security forces, public authorities and civilian users with its infrastructure for quick payload integration and ease of use.

TETRON Can Satisfy Your Different Mission Needs!

TETRON allows you to use the payload you need at high altitudes and for extended periods.

Autonomous Mission Capability:

TETRON is supplied with a flight control system that eliminates the need for piloting.

Compatible with different drones:

More than 10 different drones

Uninterrupted Mission Capability:

TETRON’s electronic architecture that covers the entire system provides you with an uninterrupted mission capability.

Portable Watchtower:

TETRON can operate as a 100 m observation tower in any location.

Covert Operation:

TETRON maintains communication with the ground via a cable, and so is immune to detection and interception by electronic warfare systems.

Resistance to Anti-Drone Systems:

TETRON makes all necessary communications via the cable connecting it to the ground, preventing jamming by anti-drone systems.

There is a TETRON for Every User:

TETRON addresses the varying needs of the armed forces, security forces, public authorities and civilian users with its infrastructure for quick payload integration and ease of use.

One Solution for Range of Needs

TETRON can work effectively in all operational scenarios involving the elevation of a payload and its extended use.

TETRON is well suited to the following roles:

Unlimited Endurance

TETRON

Military Uses

Disaster Management

Public Safety

Telecommunication

Media TV

The Solution that Goes Beyond Limits: TETRON

TETRON, an unmanned aerial vehicle (UAV) system that can be tethered to fixed or mobile platforms, offers effective and easy-to-use solutions that can satisfy the diverse needs of both public institutions and civilian users.

Portability and easy installation

Field-proven solutions

Sales, rental and training service

Can be mounted on a vehicle

Low supply and lifecycle costs

Field-proven solutions

Can satisfy different needs thanks to its modular structure

High safety and full control

Ability to fly without a GNSS signal

Compatible with more than 10 different drones

Components

TETRON: Full System Solutions for Uninterrupted Mission Capability

TETRON, which offers an easy-to-use and integrated system experience to its users, comprises several sub-systems.

Never Limit Your Line of Sight

TETRON

Payload

Drone

Active Tension Control Winch

Ground Control Station

Vehicle Integration Unit

Powertrain

Communication System

Technical Specifications Table

	Tetron-S	Tetron-M
Maximum Operational Altitude	80 m	110 m
Endurance	Unlimited	Unlimited
Maximum Power Transmission	1,8 kW	3 kW
Operating Temperature Range	-20 °C / +55 °C	-20 °C / +55 °C
Winch Speed (meters/minute)	180	180
Tether Winch	Fully Automatic	Fully Automatic
Manual Winch Control	Optional	Optional
Host Computer Interface	Serial / Ethernet	Serial / Ethernet
Tether Communication	PLC	PLC
Fibre Optic Communication	Optional	Optional
Tether Station	Portable	Portable
Environmental Protection	IP 52	IP 52

Technical Specifications Table

	Tetron-S	Tetron-M
Maximum Operational Altitude	80 m	110 m
Endurance	Unlimited	Unlimited
Maximum Power Transmission	1,8 kW	3 kW
Operating Temperature Range	-20 °C / +55 °C	-20 °C / +55 °C
Winch Speed (meters/minute)	180	180
Tether Winch	Fully Automatic	Fully Automatic
Manual Winch Control	Optional	Optional
Host Computer Interface	Serial / Ethernet	Serial / Ethernet
Tether Communication	PLC	PLC
Fibre Optic Communication	Optional	Optional
Tether Station	Portable	Portable
Environmental Protection	IP 52	IP 52

Services

Users can Access Sales, Rental and Customization Services

Rental

TETRON can be rented along with the required payloads. The rental service can also include a system operator.

Training

TETRON users can undergo theoretical and practical training at the Otonom Teknoloji facilities, at their own premises or in the field.

Quick Integration, Solutions Tailored to Needs

TETRON

Sales Models

You can purchase a full system solution, including the drone, payload and winch systems, according to your needs.
If you have a drone and want to operate uninterrupted missions, we can provide integration service for power unit and autonomous winch system.

Product Customization

TETRON can be adapted to user requirements, with need-specific changes possible in a variety of areas, such as the drone, payload, cable length, communication bandwidth, platform integration, and integration with various command and control systems. Depending on the scope of the task, customizations are completed in an average of 3 months.

After-Sales Support

The TETRON system, covered by an integrated logistics support plan, is delivered with maintenance manuals, training documents and a spare parts package. On-site or remote support can be provided throughout the lifecycle of the system. As a modular and easy-to-maintain system, TETRON offers a high mission readiness rate with the ability to remove or replace sub-units as necessary.

Uninterrupted Observation Capability

TETRON

References

TETRON has undergone successful testing in communication relay, critical facility protection, and platform-integrated reconnaissance and surveillance missions.

TETRON has already entered the inventory for use in some of these tasks, while for other roles it is currently being prepared to enter the inventory in the near future.
